Wireline Spooler is a special equipment for the workingwireline retracting of crown block and traveling block of drilling rig(also available for retracting tool of similar principle).Because it is equipped with a lead line drum, it can complete the line string up work before drilling and retracting line when finished drilling. Work is more convenient and safe, easy to operate.
|
Model |
DSJ8-D | DSJ15-D | DSJ8-Y | DSJ15-Y |
| Drive Type | Electric | Hydraulic | ||
|
Support Spacing (mm) |
1260 | 1320 | 1260 | 1320 |
|
Height of Center (mm） |
1105 | 1650 | 1105 | 1650 |
|
Rated Output Torque (KN.m) |
10 | |||
|
Rated Speed (RPM) |
3.7-18 | 0.55-17.5 | ||
|
Motor Power (KW) |
5.5KW 380V 50Hz | |||
|
Hydraulic Pressure (MPa) |
16MPa, Flow:100L/min | |||
|
Max Workload (KN) |
80 | 150 | 80 | 150 |
| Weight (KG) | 1500 | 1800 | 1500 | 1800 |
|
External Dimension (mm) |
2673x1728x1630 | 3045x2050x1845 | 2673x1728x1845 | 3045x2050x1845 |
We finished the production of 3 units of Wireline Spooler and they have passed the strict quality inspection by our QC. Now they are ready for deliver to our Egypt client.
