Product Details:
|
| Product Name: | BD Elevator | Material: | Carbon Steel |
|---|---|---|---|
| Machine Type: | Drilling Tool | Processing Type: | Forging |
| Weight: | 56kg | Tubing Range: | 1.9" To 4½"EU |
| Max Working Load: | 75t | Application: | Oilfield Wellhead Tools |
| High Light: | BD Locking Ring Drill Pipe Elevators,Tubular Handling Tubing Elevators,Forging Drill Pipe Elevators 75t |
||
BD Locking Ring Tubing Elevator Tubular Handing Tools Drill Pipe Elevators
Tubular Handing Tools- BD Elvators description:
BD series tubing elevator is an important tool for lifting or lowering suspended tubing in oil production operations in oil and gas and geological drilling departments. It's suitable for each size tubing in well service. The elevators are designed and manufactured according to a API Spec 8A specifications.
BD Tubing Elevator can handle tubing range from 1.9" to 4½"EU O.D. Rating loads of Tubing Elevators are 40t (360kN), 65t (585kN), 75t (675kN).
BD Elvators Datasheet of Tubular Handing Tools
| Specification | Tubing O.D. | Bore | Working load | ||
| Upper | Lower | ||||
| in | mm | mm | mm | t (kN) | |
| BD50 | 1.9 | 48.26 | 50.39 | 50.39 | 40 (360) 65 (585) 75 (675) |
| BD56 | 1.900EU | 48.26 | 55.96 | 55.96 | |
| BD63 | 2 3/8 | 60.33 | 62.31 | 62.31 | |
| BD68 | 2 3/8 EU | 60.33 | 68.66 | 68.66 | |
| BD76 | 2 7/8 | 73.03 | 75.01 | 75.01 | |
| BD82 | 2 7/8 EU | 73.03 | 81.36 | 81.36 | |
| BD92 | 3 1/2 | 88.9 | 90.88 | 90.88 | |
| BD98 | 3 1/2EU | 88.9 | 98.02 | 98.02 | |
| BD104 | 4 | 101.6 | 103.58 | 103.58 | |
| BD110 | 4EU | 101.6 | 110.72 | 110.72 | |
| BD117 | 4 1/2 | 114.3 | 116.66 | 116.66 | |
| BD123 | 4 1/2EU | 114.3 | 123.42 | 123.42 | |
FAQ
1. Who are we?
Topland is an integrated supplier established in 2008. We are a global group of oilfield supplies with excellent teams in more than 5 countries. such as UAE, Kuwait, Iran and Saudi Arabia. We cooperated with ADES, ECDE, EDC, SOCAR-AQS, PDL, SAKSON, ONGC etc.
2. How can we guarantee quality?
Always a double requirements and drawing checking before the production;
Always final Inspection before shipment;
3. What can you buy from us?
Drilling rig equipment and the related spares for the oil and natural gas industries. Like Rig Components, Drawworks Spare parts and Mud Pump Spare parts, Hydraulic Disc Brake,Solids Control Equipment, Drilling and Fishing Tools,Wellhead Control Equipment,Drilling Accessories, Cementing Equipment and Tools etc.
4. Why should you choose us?
4-1. Professional & Efficient, Customer Focus, Win-win Cooperation
4-2. Fast Quote, Competitive price & within shortest lead time
4-3. Complete Range of products, like spare parts which are interchangeable with most of the well-known OEM equipment.
4-2. Order tracking service
5. How is the packing?
All the packing will meet the strict export packing requirement, we surely know how important the beautiful and firm packaging to the goods.
6. What is your terms of payment?
A: Generally by T/T, 30% advance payment, the balance 70% payment should be paid before delivery. We support EXW, FOB, FCA, CFR, CIF, CIP, DAP, DDU and DDP INCO Terms.
