Fast Connector Pipe Fitting Rotary Drilling Hose Universal Self-Sealing Pipe Joint
Universal Self-Sealing Pipe Joint Description of Rotary Drilling Hose
The self-sealing pipe joint automatically opens when mounting is finished and closes when dismantled, eliminating the possibility of polluting the environment by the out-flowing media, saving the operational cost, preventing the machines from abrasion by the sand and dust coming in the pipes and machines and reducing hazards for accidents. It allows easy mounting and dismantling, reduces labor intensity and saves operating time.
The materials used fully comply with ASTM and AISI standards of USA. The product and parts are all treated against corrosion. The pipe joint provides resistance to high pressure, reliable sealing, uniform standard and good exchangeability.
The universal self-sealing pipe joint provides automatic regulation depending on the connection direction, neat and aesthetic arrangement of pipelines and reduced fatigue resistance in the pipelines.
The self- sealing pipe joint is classified into the following two major families depending on the constructions:
Fast self-sealing steel ball pipe joint and Pin key plug-in self-sealing pipe joint
Rotary Drilling Hose Universal Self-Sealing Pipe Joint Datasheet
| Nominal drift diameter mm |
Total length mm |
Max.operating pressure MPa |
Experimental pressure MPa |
Flow rate I/min |
Connecting thread |
| 6 | 62 | 52 | 78 | 16 | M14×1.5 |
| 8 | 80 | 52 | 78 | 25 | M16×1.5 |
| 10 | 90 | 52 | 78 | 40 | M22×1.5 |
| 12 | 100 | 45 | 67.5 | 50 | M27×1.5 |
| 15 | 106 | 45 | 67.5 | 63 | M30×1.5 |
| 20 | 110 | 45 | 67.5 | 100 | M36×2/1'' NPT |
| 25 | 128 | 35 | 52.5 | 160 | M42×2/1'' NPT |
| 32 | 160 | 365 | 52.5 | 250 | M52×2 |
| 40 | 190 | 21 | 31.5 | 400 | M60×2 |
| 51 | 204 | 16 | 24 | 630 | M68×2 |
