Product Details:
|
| Product Name: | Drilling Swivel Spare Parts | Model No.: | SL250, SL450, SL450S, SL586 |
|---|---|---|---|
| Machine Type: | Drilling Swivel | HS Code: | 84139100 |
| Certification: | ISO 9001:2000 | Applicable Medium: | Oil Well |
| High Light: | SL225 Drilling Rig Spare Parts,wash pipe packing SL135,Drilling Rig Spare Parts SL250 |
||
Drilling Rig Spare Parts SL135/SL225/SL450/SL586 Drilling Swivel
Topland supplies all types of oil drilling equipment like ZJ30, ZJ40, ZJ50, ZJ70, ZJ90 and rig parts: Mud pump, Hook, Rotary Table, Swivel, Crown block, Travelling Block, iron roughneck, etc. Our products have certificated by international institutions, API and ISO, GOST. the quality is guaranteed. We always stick to the principle of ensuring quality and servicing customers.
The Drilling Swivel wash pipe and packing assembly is of cartridge type.
It can be replaced on the drill floor without disconnecting the rotary hose and the gooseneck.
The contact surface radius of the bail conforms to API 8Aspecification.
Expendable parts have the better interchangeablitity of drilling swivels.
The main Model available at SL135,SL225, SL250, SL450, SL450S, SL586
Specification of Driling Swivel Washpipe
| Model | SL90 | SL135 | SL225 | SL450 | SL675 | |
| Max. static load KN | 900 | 1350 | 2250 | 4500 | 6750 | |
| Max. rotary speed r/min | 300 | 300 | 300 | 300 | 300 | |
| Max. working pressure MPA (psi) | 25 (3570) |
35 (5000) |
35 (5000) |
35 (5000) |
53 (7000) |
|
| Clearance between bail and gooseneck mm (in) |
435 (17 1/8) |
495 (19 1/2) |
540 (21 1/4) |
549 (21 5/8) |
640 (25) |
|
| Center pipe diameter mm(in) | 64 (2 1/2) | 64 (2 1/2) | 75 (3) | 75 (3) | 102 (4) | |
| Center pipe upper screw thread | Connect to center pipe API In |
4 1/2 REG LH |
4 1/2 REG LH |
6 5/8 REG LH |
7 5/8 REG LH |
8 5/8 REG LH |
|
Center pipe lower Screw thread |
Connect to Kelly API in |
6 5/8 REG LH |
6 5/8 REG LH |
6 5/8 REG LH |
6 5/8 REG LH |
6 5/8 REG LH |
| Gooseneck connection screw thread | 3″-8 teeth/inch | 3″-8 teeth/inch | 4″-8 teeth/inch | 4″-8 teeth/inch | 4″-8 teeth/inch | |
| Dimension (L x W x H) mm |
2505×758 ×840 |
2505×758 ×840 |
2880×1026 ×1065 |
3015×1096 ×1065 |
3649×1450 ×1162 |
|
| Weight kg | 940 | 1345 | 2402 | 3310 | 6230 | |
| Note: For above models, spinner (makeup and breakout) is optional. | ||||||
| Swivel parts include | ||
| Mark plate | Spring washer | Bolt . |
| Guard | Hanging beam | Nut |
| Wjre plug | Seat plate | Wjre plug |
| Nameplate | Spring washer | Spring washer |
| Cotter nut | Guard | Locating block |
| Oil nipple | Sheave | Screw |
| Left side plate | Oil nipple | Spring washer |
| Cotter nut | Cotter nut | Seat plate |
| Bearing | Press plate | Cotter pin |
| Shaft | Bearing | Press plate |
| Hanging beam pin | Cotter nut | Lifing bail |
| Screw . | Screw | Nut |
| Right side plate | Sheave | Bolt |
| Guard pin | Hanging beam pin | Liting bajl pin |
| Screw | Cotter pin | Locating block |
| Guard pin | Screw . | Cotter pin |
| Swivel SL135,SL225, SL250, SL450, SL450S, SL586 part no. | ||
| AB450004-01 | AB450001 -01 | AB315001 -14 |
| T201-1004 | 420101121116004000 | AB170001-17 |
| AB225001-14 | AB450004-0300003 | AB675001-1103 |
| AB450004-02 | AB450001 -0200 | AB315001 -18 |
| 420101050704001000 | 420101030710002000 | AB225001-020001 |
| AB315001-0201 | AB675001-00 | AB170001 |
| AB450004-0300 | AB450001 -06 | T201-0408 |
| 420703020812020000 | 420201070720045000 | AB225001-12 |
| AB315001-12 | AB675001-01 | AB180001 |
| AB450004-04 | AB450001 -07 | AB450004 |
| 420703020808010000 | 420503011201600000 | AB585002 |
| AB315001-14 | AB675001-020001 | AB225003 |
| AB450004-0500 | AB450001 -08 | AB450005 |
| 5202 10050300250000 | 420503011161 600000 | AB585003 |
| AB450001-020001 | AB675001-050002 | AB225001 |
| AB450004-06 | AB450001 -09 | AB450006 |
| 61302011152101000 | AB170001-12 | AB585004 |
| AB450004-00 | AB675001-110202 | AB315003 |
| AB450004-07 | AB450001 -12 | AB675003 |
| 430104030796100000 | AB170001-16 | AB675001 |
| AB450004-0300002 | AB675001-110204 | AB315004 |
