Product Details:
|
| Product Name: | Xmas Tree & Hydraulic Choke Manifold | Media: | Mud,oil And Drilling Fluid |
|---|---|---|---|
| Type: | Choke Manifold | Design Pressure: | 105Mpa |
| Processing Type: | Forging | Product Specification Level: | PSL1, PSL2, PSL3, PSL4 |
| Usage: | Well Drilling | End Connection Type: | Flange |
| Application: | Wellhead Test Manifold | Performance Requirement: | PR1~PR2 |
| Work Temperature: | PU(-29℃-121℃) | Material: | Carbide |
| High Light: | API 16c Hydraulic Choke,Wellhead Equipment Hydraulic Choke,Kill Manifold For Well Drilling |
||
Wellhead Equipment API 1 6c Hydraulic Choke and Kill Manifold for Well Drilling
Manifold Control Valve -Mud Gate Valve Description
Wellhead test manifold are to throttle the fluid, oil and gas wells can work under thw different working system.
When the pressure inside the well rises, opening/closing the choke valves (including manual chokes, hydraulic chokes and positive chokes) on the choke manifold can allow the release of the fluid inside the well so as to control casing pressure, which can be directly blown out through the gate valve if the casing pressure is quite high.
| pressure level parameter |
35Mpa (5000psi) | 70Mpa (10000psi) | 105Mpa (15000psi) |
| color | blue | yellow | red |
| Model | JG/S52-35 | JG/S78-70 | JG/S78-105 |
| Design pressure | 35Mpa | 70Mpa | 105Mpa |
| Weight | 2530kg(5578Ib) | 3580kg (7892.5Ib) | 4630kg (10260Ib) |
| Dimension | 1802(L) X 1339(W) X 680(H)MM 70.9 X 52.7 X 26.8 in | 2516(L) X 1824(W) X 799(H)MM 99.1 X 71.8 X 31.5 in |
3270(L)X2371(W)X1038.7(H)MM 128.83 X 93.34 X 40.95 in |
| Material Level | EE | EE | EE |
| product specification level | PSL3 | PSL3 | PSL3 |
| work temperature | PU(-29℃-121℃) | PU(-29℃-121℃) | PU(-29℃-121℃) |
| product performance level | PR1 | PR1 | PR1 |
| Nozzle | fixed and adjustable nozzle | fixed and adjustable nozzle | fixed and adjustable nozzle |
| Characteristics | Five gate design | Five gate design | Five gate design |
| work medium | Mud,oil and drilling fluid | Mud,oil and drilling fluid | Mud,oil and drilling fluid |
| Connection type | flange | flange | flange |
