Product Details:
|
| Type: | Rotary Drilling Rig Drawwork | Warranty: | 12 Months |
|---|---|---|---|
| Coating: | Anti-corrosion Painting | Material: | Iron |
| Core Components: | Engine, Bearing, Motor, Gear | Processing Type: | Casting |
| Application: | Oil And Gas Well Drilling | Dimension: | 7930*3194*2930 |
| Weight: | 4300kg | Power KW/hp:: | 1470/2000 |
| High Light: | Oilfield Drilling Rig Drawworks Parts,JC20 Drilling Rig Drawworks,API 7K Oilfield Drawworks |
||
Drawworks JC20-JC70 With API Standard For Oilfield Drilling Rig
Drawworks Parts Description:
Drawworks is necessary hoisting mechanism on a drilling rig. Essentially, drawworks is one large winch that spools off or takes in the drilling line and thus raises or lowers the drill stem and bit.
The sheet of Drawworks Parts
| Type | JC20 | JC30 | JC40 | JC50 | JC70 |
| Range of Drilling Depth | 1200-2000 | 1600-3000 | 2500-4000 | 3500-5000 | 4500-7000 |
| 1100-1800 | 1500-2500 | 2000-3200 | 2800-4500 | 4000-6000 | |
| Rated PowerKW(hp) | 440(600) | 550(750) | 735(1000) | 1100(1500) | 1470(2000) |
| Max.Fastline Pull | 200 | 210 | 275 | 340 | 485 |
| Dia.Of Wire Line | φ29(1 1/8) | φ29(1 1/8) | φ32(1 1/4) | φ35(1 3/8) | φ38(1 1/2) |
| Size of Drum Groove | φ560×1120 | φ560×1005.72 | φ640×1142 | φ685×1245 | φ770×1436 |
| (Dia.×Length) | (22×44) | (22×39 3/5) | (25 1/4×45) | (27×49) | (30×56 1/2) |
| Brake Rim (Dia.×Length) | φ1067×267 | φ1168×265 | φ1270×267 | φ1600×76 | |
| (42×10 1/2) | (46×10 1/2) | (50×10 1/2) | (63×3) | ||
| Brake Disc (Dia.×Length) | φ1400×40 | φ1500×76 | φ1600×76 | φ1600×76 | |
| (55×1 3/5) | (59×3) | (63×3) | (63×3) | ||
| Auxiliary Brake | SDF20 | FDWS30 | FDWS40 | DS50 | DS70 |
| Overall Dimension (L×W×H) | 2450×5500×2545 | 6140×2835×2562 | 6600×2890×2670 6450×3553×2429 | 7000×2955×2780 | 7930×3194×2930 |
| Weight | 17528 | 24120 | 29000/28000 | 7000×2955×2780 | 43000 |
