Product Details:
|
| Product Name: | 5 Inch Impeller Shaft Casting Sand Pump Spare Parts Drilling Rig Spare Parts | HS Code: | 8431431000 |
|---|---|---|---|
| Color: | Customizable | Max.Capacity: | >400 L/min |
| Impeller Number: | Multistage Pump | Driving Type: | Motor |
| Max.Head: | 30-50m | Condition: | New |
| Structure: | Sand Pump Spare Parts | ||
| High Light: | Casting Sand Pump Impeller Shaft, 5 Inch Impeller Shaft, Impeller Shaft Drilling Rig Spare Parts | ||
5 Inch Impeller Shaft Casting Sand Pump Spare Parts Drilling Rig Spare Parts
Mainly supplies to solids control circulating system of oilfield drill rig, and is used to provide drilling liquid with a certain discharge capacity and pressure to desander, desilter and mud mixer, to assure these equipments work efficiently.
Hydraulic excavation, filling unit hydraulic mechanization construction, is to simulate the nature of water scour principle, by hydraulic action to excavate, transport and fill the work, water through the high-pressure pump pressure, through the nozzle of the water gun, injection of high-pressure high-speed water column, water column impact soil, soil wetting, disintegrating, mixing into mud and mud mixture, and then lifted by the vertical mud pump, It is transported to the battlefield through mud pipes.
Drilling Rig Spare Parts Sand Pump Spare Parts Introduction
1. Size of inlet: 4 inches, 6 inches,8 inches,10 inches
2.Material: cast iron, cast steel
3.Working mode: horizontal or vertical
Sand Pump Spare Parts Advantage of Drilling Rig Spare Parts
1. One part of products is self- priming, no need to pour into pilotage water. Operation is very simple.
2. High efficiency, wear resistant and big flow channel suitable for working site with many pebbles.
3. Can be assembled with motor and diesel engine.
Drilling Rig Spare Parts Sand Pump Spare Parts Technical Parameters:
| Model | Flow | Head Lift | Suction | Power | Speed | Inlet/Outlet |
| (m³/h) | (m) | (m) | (kw) | (r/min) | (mm) | |
| 6" sand pump | 200 | 20 | 30 | 30 | 1200 | 150/150 |
| 8" sand pump | 400 | 20 | 30 | 80 | 1200 | 200/200 |
| 10" sand pump | 600 | 20 | 30 | 110 | 1100 | 250/250 |
| 12" sand pump | 1000 | 20 | 30 | 200 | 1000 | 300/300 |
| 14" sand pump | 2500 | 25 | 10 | 400 | 800 | 350/350 |
| 16" sand pump | 3000 | 25 | 10 | 500 | 750 | 400/400 |
FAQ
1. Who are we?
Topland is an integrated supplier established in 2008. We are a global group of oilfield supplies with excellent teams in more than 5 countries. such as UAE, Kuwait, Iran and Saudi Arabia. We cooperated with ADES, ECDE, EDC, SOCAR-AQS, PDL, SAKSON, ONGC etc.
2. How can we guarantee quality?
Always a double requirements and drawing checking before the production;
Always final Inspection before shipment;
3. What can you buy from us?
Drilling rig equipment and the related spares for the oil and natural gas industries. Like Rig Components, Drawworks Spare parts and Mud Pump Spare parts, Hydraulic Disc Brake,Solids Control Equipment, Drilling and Fishing Tools,Wellhead Control Equipment,Drilling Accessories, Cementing Equipment and Tools etc.
4. Why should you choose us?
4-1. Professional & Efficient, Customer Focus, Win-win Cooperation
4-2. Fast Quote, Competitive price & within shortest lead time
4-3. Complete Range of products, like spare parts which are interchangeable with most of the well-known OEM equipment.
4-2. Order tracking service
5. How is the packing?
All the packing will meet the strict export packing requirement, we surely know how important the beautiful and firm packaging to the goods.
6. What is your terms of payment?
A: Generally by T/T, 30% advance payment, the balance 70% payment should be paid before delivery. We support EXW, FOB, FCA, CFR, CIF, CIP, DAP, DDU and DDP INCO Terms.
Contact Person: Lucy
Tel: 13991954932
Fax: 86-021-61925822
