Product Details:
|
| Warranty:: | 1 Year | Weight (KG):: | 300kg |
|---|---|---|---|
| Usage:: | Well Drilling | Product Name:: | Vacuum Pump |
| Certification:: | API | Core Components:: | Pump |
Oilfield Solids Control Equipment High Capacity Solid Vacuum Pump Vacuum Sludge Pump
Description:
Vacuum Degasser is adapted to get rid of various cut-in gases in the drilling fluids. Vacuum degasser is very important for returning mud gravity, stabilizing mud viscosity and reducing drilling cost. Therefore, it works as one type mud cleaning equipment. As it is placed after the shale shaker, so we call it second stage mud cleaning equipment in mud recycling system. At the same time vacuum degasser can be used as a heavy-power agitator.
Features:
1.Self-contained degasser unit operation without feeding pump.
2.Liquid Level Sensor for safety operation.
3.Degasser have another function like a big size agitator for mixing mud before feeding to desander desilter.
4.Technical and spare parts support in many countries.
Tehnical Parameter:
| ModeI | SP-40B | SP-20B | SP-10B |
| Max Capacity (m³/h) | 40m³/h | 20m³/h | 10m³/h |
| Inlet/Outlet Size(Inch) | 4"(114mm) | 4"(114mm) | 3"(89mm) |
| Vacuum Degree | 85Kpa/25 inch HG(Mercury Column) | ||
| Max Suction Distance (m) | 50m | ||
| Max Discharge Distance (m) | 1000m | 500m | |
| Max Solids Content | 80% | ||
| Max Solids Size (mm) | 75mm | 50mm | |
| Pressure Request | 550Kpa-785Kpa (80- 114PSI) | 550Kpa-690Kpa (80-100PSI) | |
| Air Demand | 17m³/min (600CFM) | 8m³/min(280CFM) | 4.3 m³/min(150CFM) |
| Weight(kg) | 892kg | 386kg | 320kg |
| Dimension | 1690*1468*1983mm | 1421*900*1448mm | 1283*800*1370mm |
